-15-
g9298/g9299/g9300 rotary table
SECTION 4: ACCESSORIES
ACCessories
figure 13. test indicator.
G9610—Test Indicator
0.03
" range/0.001" resolution
G9611—Test Indicator
0.008" range/0.0001" resolution
G9612—Test Indicator
0.030" range/0.0005" resolution
these test indicators have an easy to read dial
and a pivoting stylus that moves at right angles to
the dial face.
G9640— 90° Wide Base Square 3" x 5"
G9641— 90° Wide Base Square 4" x 6"
G9642— 90° Wide Base Square 5" x 8"
grade 0, heavy-duty stainless steel 90° precision
squares feature wide bases for stability. perfect
for all setup and inspection work.
figure 12. 90° precision Wide-Base squares.
G1075—52-pC. Clamping Kit 1 ⁄
2
" T-Nut
G1076—52-pC. Clamping Kit 5 ⁄
8
" T-Nut
this clamping kit includes 24 studs, 6 step block
pairs, 6 t-nuts, 6 flange nuts, 4 coupling nuts, and
6 end hold-downs. the rack is slotted so it can be
mounted close to the machine for easy access.
figure 14. 52-pC. Clamping Kit.
G9629—universal Indicator Holder
Mount your test indicator right on your mill for
guaranteed accurate readings. C-frame holder
mounts with a single screw directly on the quill
and does not interfere with the cutting tool.
Clamping diameter is 1
7 ⁄
8
". the length from the
clamping bracket to the indicator is 4 1 ⁄
2
". suitable
for all popular indicators with a 5 ⁄
32
" shank.
figure 15. g9629 universal indicator holder.
