Operator’s Manual
Third Edition • Fourth Printing
Part No. 114002
Genie AWP Super Series
33
SPECIFICATIONS
Outrigger Specifications
Standard Base
AWP-36S
AWP-40S
Outrigger footprint
83
1
/
4
x 75
1
/
4
in
89 x 81 in
(l x w) ANSI / CSA
2.1 x 1.9 m
2.3 x 2.0 m
Outrigger footprint
83
1
/
4
x 75
1
/
4
in
89 x 81 in
(l x w) CE / AUS Indoor
2.1 x 1.9 m
2.3 x 2.0 m
Outrigger footprint
139 x 131 in
153 x 145 in
(l x w) CE / AUS Outdoor
3.5 x 3.3 m
3.9 x 3.7 m
Corner access/wall access*
28
1
/
2
/ 14
1
/
4
in
31
1
/
4
/ 14
1
/
2
in
ANSI / CSA
72.7 / 36.2 cm
79.4 / 37.1 cm
Corner access/wall access*
28
1
/
2
/ 14
1
/
4
in
31
1
/
4
/ 14
1
/
2
in
CE / AUS Indoor
72.7 / 36.2 cm
79.4 / 37.1 cm
Corner access/wall access*
52 / 31
1
/
4
in
50
3
/
4
/ 28
3
/
4
in
CE / AUS Outdoor
1.3 m / 79.3 cm
1.3 m / 73 cm
* Corner of platform top rail to corner of wall with ability to rotate leveling jack.
Outrigger Specifications
Narrow Base / Rough Terrain Base
AWP-20S
AWP-25S
AWP-30S
Outrigger footprint
64 x 48
1
/
4
in
64 x 48
1
/
4
in
71
1
/
2
x 58 in
(l x w) ANSI / CSA
1.6 x 1.2 m
1.6 x 1.2 m
1.8 x 1.5 m
Outrigger footprint
71
1
/
4
x 58 in
71
1
/
4
x 58 in
74
1
/
2
x 65
1
/
2
in
(l x w) CE / AUS Indoor
1.8 x 1.5 m
1.8 x 1.5 m
1.9 x 1.6 m
Outrigger footprint
83
1
/
4
x 74 in
95
1
/
4
x 89
3
/
4
in
112 x 112 in
(l x w) CE / AUS Outdoor
2.1 x 1.9 m
2.4 x 2.2 m
2.8 x 2.8 m
Corner access/wall access*
14
1
/
4
/ 8
1
/
2
in
13 / 6 in
18
1
/
2
/ 7
1
/
4
in
ANSI / ANSI
36.2 / 21.6 cm
33 / 15.2 cm
47 / 18.4 cm
Corner access/wall access*
21 / 12
1
/
4
in
19
1
/
2
/ 9
3
/
4
in
22 / 9 in
CE / AUS Indoor
53.3 / 31.1 cm
49.5 / 24.7cm
55.8 / 22.8 cm
Corner access/wall access*
76.2 / 44.4 cm
98.4 / 53.3 cm
1.3 m / 67.3 cm
* Corner of platform top rail to corner of wall with ability to rotate leveling jack.
Continuous improvement of our products is a Genie policy. Product specifications are subject to change
without notice or obligation.
