Operator’s Manual
Third Edition • Fourth Printing
28
Genie AWP Super Series
Part No. 114002
Decals
Part No. Description
Quantity
27838
Warning - Tilt-back Hazards/Instructions
1
27839
Label - Sliding T-handle
1
27840
Label - Retaining Pin
1
27841
Label - Stop Bracket
1
27842
Label - Loading Pivot
1
27843
Label - Tilt-back Strut
1
27844
Label - Strut Socket
1
27857
Caution - Pipe Plug
1
27863
Warning - Collision Hazard
3
27864
Notice - Lower Stop Bracket Before . . .
1
27865
Label - Bubble Level
1
27867
Label - Swivel Lock
1
27868
Danger - Relief Valve
1
27872
Danger - Tip-over Hazard, Outriggers
1
27873
Notice - Maintain Firm Grasp
1
27874
Label - Insert Retaining Pin
1
28174
Label - Power to Platform, 230V
2
28235
Label - Power to Platform, 115V
2
28372
Caution - Quick Disconnect
1
31070
Danger - Tip-over Hazard, Moving
1
31071
Warning - Failure to Read
1
31245
Warning - Collision Hazard
1
37141
Notice - Manual Lowering Instructions
1
37142
Notice - Operating Instructions
1
37143
Notice - Max Capacity 300 lbs / 136 kg
AWP-40S
1
37144
Notice - Max Capacity 350 lbs / 159 kg
AWP-20S, 25S, 30S, 36S
1
Part No. Description
Quantity
37145
Label - Manual Lowering Valve
1
38122
Label - Manual Storage Container
1
38142
Label - Circuit Breaker, AC models
1
40434
Label - Lanyard Anchorage Point
1
41266
Label - Interlock Display, Air Models,
Standard Base
1
41268
Label - Interlock Display, Air Models,
Narrow Base and Rough Terrain Base
1
52996
Cosmetic - Genie Logo
1
52999
Cosmetic - AWP-20S
2
62992
Cosmetic - AWP-25S
2
62993
Cosmetic - AWP-30S
2
62994
Cosmetic - AWP-36S
2
62995
Cosmetic - AWP-40S
2
72086
Label - Lifting Eye
1
82366
Label - Chevron Rykon
1
82780
Label - Interlock Display
1
82781
Label - Interlock Display
1
82802
Label - Function Enable
1
82907
Danger - Battery Charger Safety
1
82975
Danger - Collision Hazard
1
82986
Danger - Electrocution Hazard
1
97522
Label - Wheel Load
4
97523
Label - Outrigger Load
4
114008
Notice - Max Side Force 50 lbs / 222 N,
ANSI/CSA
1
114009
Notice - Max Manual Force 45 lbs / 200N,
AUS
1
114011
Danger - General Safety
1
Inspection for Decals with Words
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and
in place.
