Operator’s Manual Third Edition • Fourth Printing
30 Genie AWP Super Series Part No. 114002
DECALS
Inspection for Decals with
Symbols
Determine whether the decals on your machine
have words or symbols. Use the appropriate
inspection to verify that all decals are legible and in
place.
Part No. Description Quantity
28174 Label - Power to Platform, 230V 2
28235 Label - Power to Platform, 115V 2
40434 Label - Lanyard Anchorage Point 1
52996 Cosmetic - Genie Logo 1
52999 Cosmetic - AWP-20S 2
62992 Cosmetic - AWP-25S 2
62993 Cosmetic - AWP-30S 2
62994 Cosmetic - AWP-36S 2
62995 Cosmetic - AWP-40S 2
82481 Danger - Battery Charger Safety 1
82487 Label - Read the Manual 1
82614 Caution - Collision Hazard 1
82780 Label - Interlock Display 1
82781 Label - Interlock Display 1
82802 Label - Function Enable 1
82913 Danger - Max Capacity, 159 kg
AWP-20S, 25S, 30S, 36S
1
82914 Danger - Max Capacity, 136 kg
AWP-40S
1
82915 Label - Manual Lowering Valve 1
82916 Danger - Maximum Manual Force 200N,
CE
1
Part No. Description Quantity
82973 Warning - Insert Pin 1
82974 Warning - Collision Hazard 1
82976 Danger - Wind Speed, 51 cm Outrigger 4
82977 Danger - Wind Speed, 66 cm Outrigger 4
82978 Danger - Wind Speed, 77 cm Outrigger 4
82979 Danger - Wind Speed, 91 cm Outrigger 4
82980 Danger - Wind Speed, 1.02 m Outrigger 4
82981 Danger - Wind Speed, 1.17 m Outrigger 4
82982 Danger - Wind Speed, 1.52 m Outrigger 4
82983 Danger - Wind Speed, 1.91 m Outrigger 4
82984 Danger - Wind Speed, 2.16 m Outrigger 4
82987 Danger - Electrocution Hazard 1
82988 Label - Read the Manual, Tilt-back Frame 1
97522 Label - Wheel Load 4
97523 Label - Outrigger Load 4
97815 Label - Lower Mid-rail 1
114010 Danger - Maximum Side Force 222N,
ANSI
1
