Operator’s Manual Third Edition • Fourth Printing
Part No. 114002 Genie AWP Super Series 25
Tilt-back Operation Instructions
Observe and obey:
The retaining pin must be inserted to prevent the
spring-loaded tilt-back frame from dropping.
Do not tilt the machine back unless the area is
clear of personnel and obstructions.
Do not stand behind or under the tilt-back frame
when raising or lowering it.
Tilt-back Frame
The Genie AWP Super
Series has a tilt-back
frame which allows the
machine to roll through a
standard doorway. The
tilt-back frame is
standard equipment on
standard base AWP-36S
and 40S models, and
optional on standard base
AWP-15S, 20S, 25S and
30S models. The tilt-back
frame is not available on
narrow base machines or
rough terrain base machines.
Lifting Instructions
The number of people required to load and unload a
machine is dependent on a number of factors,
including but not limited to:
· the physical condition, strength and
disabilities or prior injuries of the people
involved
· the vertical and horizontal distances the
machine has to be moved
· the number of times the machine will be
loaded or unloaded
· the stance, posture and grip used by the
people involved
· the lifting techniques used
· the site conditions and weather in which the
activity is being performed (i.e., slippery, icy,
raining)
The appropriate number of people and proper lifting
techniques must be used to prevent physical injury.
Tilt-back Operation Instructions
