G0524 Rip Saw -41-
201 PB35M HEX BOLT M12-1.75 X 40
202 PLW05M LOCK WASHER 12MM
203 P0524203 SPECIAL WASHER 12 X 30 X 5MM
204 P0524204 PRESS PLATE
205 P0524205 MAIN SPINDLE
206 PSB01M CAP SCREW M6-1 X 16
207 P0524207 COVER, FRONT
208 P7208 BALL BEARING 7208
209 P0524209 RING
210 P0524210 RING
211 P0524211 STOPPER, FRONT
212 PTLW10M EXT TOOTH WASHER 40MM
213 P0524213
SPANNER LOCK NUT M40-1.5LH
214 P0524214 SPECIAL NUT M12-1.75
215 P0524215 SPINDLE SHAFT BOX
216 PN03M HEX NUT M8-1.25
REF PART # DESCRIPTION
217 PB20M HEX BOLT M8-1.25 X 35
218 P0524218 LOCK COLLAR
219 PSS16M SET SCREW M8-1.25 X 10
220 P0524220 SHAFT
221 P0524221 SPECIAL NUT TW22-P5
222 P6207 BALL BEARING 6207ZZ
223 P0524223 STOPPER, REAR
224 P0524224 COVER, SPINDLE
225 PSB07M CAP SCREW M6-1 X 30
226 P0524226 SPACER
227 P0524227 PULLEY, SPINDLE
228 PK85M KEY 10 X 8 X 40
229 PW04M FLAT WASHER 10MM
230 PLW06M LOCK WASHER 10MM
231 PSB64M CAP SCREW M10-1.5 X 25
232 P0524232 SAW BLADE 12" X 48T X 4W
REF PART # DESCRIPTION
