-8-

G0524 Rip Saw

Figure 3. Overload relays.

4. Remove the RH10E/7C overload relay

(

Figure 3) and replace it with an RH10E/4C

(3-5A) type, with the dial set to 4A.

5. Remove the RH18/20 overload relay (Figure

3) and replace it with an RH18/15 (12-18A)
type, with the dial set to 12A.

6. Wire the main motor and the feed motor

as shown on the diagrams on the inside
of each motor wire cover. After connecting
wires together with the screws, nuts, and
washers provided in the 440V conversion kit,
completely wrap the connecting hardware in
electrical tape so no metal is exposed where
the wires connect.

Note—Figures 4a and 4b have been provid-
ed for your reference and were current at the
time that this manual was written. However,
always use the diagram on the wire cover
that comes with your motor!

Figure 4a. 440V main motor wiring.

��

�

��

��
��

��

RH10E/7C

RH18/20

Figure 4b. 440V feed motor wiring.

��

�

�
�

�

��
