FS-8704-13 GE-SRTP Driver Manual
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 6
4.4.2 Driver Specific Map Descriptor Parameters
Column
Title
Function Legal Values
Node_Name Name of Node to fetch data from One of the node names specified in
“Client Node Descriptor” above
Data_Type Data type
Use one of the Data Types specified in brackets.
Discrete Inputs (%I)
Discrete Outputs (%Q)
Discrete Temporaries (%T)
Discrete Internals (%M)
Genius Global Data (%G)
Analog Inputs (%AI)
Analog Outputs (%AQ)
Registers (%R)
%SA Dis crete
%SB Discrete
%SC Discrete
%S Discrete (%S)
Length Length of Map Descriptor
Ensure that the length does not exceed the table length
in the PLC. 1 - 1000
Address Starting address of read block / write block
The 1
st element of each Data type Table is referred to
as address one.
1 , 2 , 3
Positive whole numbers
Format Use to override the default format for obtaining data.
Bit tables are by default read by reading whole bytes
at a time (If the Length is 10 then 10 bytes of data are
read and placed in 10 data array locations)
If you wish to read bits instead then use this parameter
. (If the Length is 10 then 10 bits are read and each bit
is stored in its own location.) Bit, Byte
The format for %AI,%AQ and %R
cannot be changed.
4.4.3 Timing Parameters
Column Title Function Legal Values
Scan_Interval Rate at which data is polled >0.1s
