4.4.5 Map Descriptor Example 2 – Simple Write
This example writes data from the Fieldserver data array called DA_AO to the PLC identified as NODE1. The write is repeated every 5 seconds. Ten word
values are written to the PLC’s %AQ Data Table starting at location 20.
Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Scan_Interval, node_name, Address, Length, Data_Type
Write_AO , DA_AO , 0 , wrbc , 5.0s , Node1 , 20 , 10 , %AQ
Write
continuously Write to the %AQ
(Analog Output)
table in the PLC. Write to PLC
Table element
number 20 to 29
inclusive (10
elements)
