FS-8704-13 GE-SRTP Driver Manual
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 5
4.2 Client Side Connections
Section Title
Adapter
Column Title Function Legal Values
Adapter Specify which port the device is
connected to the FieldServer N1
Protocol Specify protocol used GE_SRTP, SRTP
Example
// Client Side Connections
Connections
Adapter, Protocol
N1, SRTP
4.3 Client Side Nodes
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for node Up to 32 alphanumeric
characters
Node_ID Node ID of physical server node
(PLC) 1-255
IP_Address IP address of physical server node
(PLC) Must be on the same subnet as
the server or gateway
Protocol Specify protocol used GE_SRTP, SRTP
Adapter Specify on which port the device is
connected to the FieldServer N1
Example
// Client Side Nodes
Nodes
Node_Name, Protocol, IP_Address, Adapter
Node_A, SRTP, 192.168.1.174, N1
4.4 Client Side Map Descriptors
4.4.1 FieldServer Specific Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name Name of Data Array where data is
to be stored in the FieldServer One of the Data Array names from
“Data Array” section above
Data_Array_Location Starting location in Data Array 0 to maximum specified in “Data
Array” section above
Function Function of Client Map Descriptor RDBC, WRBC, WRBX
