FS-8704-13 GE-SRTP Driver Manual
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 (408) 262-2299 fax: (408) 262-9042
Visit our website: www.fieldserver.com E-mail: [email protected]
Page 4
4. Configuring the FieldServer as a GE-SRTP Driver Client
For a detailed discussion on FieldServer configuration, please refer to the instruction manual for the
FieldServer. The information that follows describes how to expand upon the factory defaults
provided in the configuration files included with the FieldServer (See “.csv” files on the driver
diskette).
This section documents and describes the parameters necessary for configuring the FieldServer to
communicate with a GE-SRTP Driver Server.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In
order to enable the FieldServer for GE-SRTP Driver communications, the driver independent
FieldServer buffers need to be declared in the “Data Arrays” section, the destination device
addresses need to be declared in the “Client Side Nodes” section, and the data required from the
servers needs to be mapped in the “Client Side Map Descriptors” section. Details on how to do this
can be found below.
Note that in the tables, * in dicates an optional parameter, with the bold legal value being the
default.
4.1 Data Arrays
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Provide name for Data Array Up to 15 alphanumeric
characters
Data_Format Provide data format. Each data array can only
take on one format. FLOAT, BIT, UInt16, SInt16,
Packed_Bit, Byte,
Packed_Byte, Swapped_Byte
Data_Array_Length Number of Data Objects. Must be larger than
the data storage area required for the data
being placed in this array. 1-10,000
Example
// Data Arrays
Data_Arrays
Data_Array_Name,
Data_Format, Data_Array_Length
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Byte, 200
DA_DO_01, Byte, 200
