Friedrich MR30C3F - Manual (Page 13)

12V K101
DW12D1-O(M)
3
2
4
1
C108
3.3
L102
N200500K1D7C
12V
B
B
B
B
CN100
UL1007 AWG26 2P
POWER RELAY CONTROL
W29
BROWN
W28
ORANGE
W26
ORANGE
W25
ORANGE
PTC OUT
C106
3.3
L101
RCH3818 - 022PF07
4 3
1 2
CT OUT
W21
GRAY
B
W9
BLACK
L100
RCH3818 - 022PF07
C103
3.3
C104
0.033
C100
3.3
VA100, VA101
470V
SA100
RA - 302M
4 3
1 2
B
B
B
B
B
B
B
F100
FSL 250 3.15 (EM)
W17
BLACK
W18
WHITE
W2
WHITE
W3
GREEN
W19
BLACK
W20
WHITE
TO
INDOOR UNIT
N
L
N
L
W1
BLACK
EARTH
AC VOLT OUT
C105
0.033
POWER SOURCE
2008.01.09 12
OUTDOOR UNIT
POWER SUPPLY PCB ASSEMBLY
K05CW-0503HUE-FL0
C200 - C203
660 / 450V x 4
+ + + +
R200
220K
<2W>
W13
VIOLET
W12
WHITE
W8
BLUE
W7
YELLOW
P
N
POWER-G
B
B
B
B
OUTDOOR UNIT
CONDENSOR PCB ASSEMBLY
K05FB-0500HUE-P0
