C141-E099-01EN 4 - 11
Table 4.2 Transfer rate of each zone
Zone 0 1 2 3 4 5 6 7
Cylinder 0
to
1199
1200
to
3479
3480
to
4799
4800
to
5759
5760
to
6719
6720
to
7559
7560
to
8999
9000
to
10319
Transfer rate
[MB/s]
37.73 36.43 35.78 34.56 34.56 34.11 33.03 31.97
Zone 8 9 10 11 12 13 14
Cylinder 10320
to
11879
11880
to
12599
12600
to
13799
13800
to
15359
15360
to
16919
16920
to
18239
18240
to
19679
Transfer rate
[MB/s]
30.67 30.02 28.80 27.27 25.71 24.26 21.51
The MPU transfers the data transfer rate setup data to the RDC that includes the time base
generator circuit to change the data transfer rate.
