C141-E099-01EN 1 - 5
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers.
Table 1.2 Model names and product numbers
Model Name Capacity
(user area)
Mounting
Screw
Order No. Remarks
MPF3102AT 10.24 GB No. 6-32UNC CA05423-B321 512 KB Data Buffer
MPF3153AT 15.37 GB No. 6-32UNC CA05423-B331 512 KB Data Buffer
MPF3204AT 20.49 GB No. 6-32UNC CA05423-B341 512 KB Data Buffer
1.3 Power Requirements
(1) Input Voltage
•
+ 5 V ±5 %
•
+ 12 V ±8 %
(2) Ripple
+12 V +5 V
Maximum 200 mV (peak to peak) 100 mV (peak to peak)
Frequency DC to 1 MHz DC to 1 MHz
(3) Current Requirements and Power Dissipation
Table 1.3 lists the current and power dissipation.
