Table 1.3 Current and power dissipation
Typical RMS current (*1) [mA]
+12 V +5 V
Model MPF3102AT MPF3153/
MPF3204AT
All Models MPF3102AT MPF3153/
MPF3204AT
Spin up 1600
1800 peak
1600
1800 peak
570
600 peak
22.1 22.1
Idle (Ready) (*3) 175 185 400 4.1 4.2
R/W (On Track) (*4) 240 250 500 5.4 5.5
Seek (Random) (*5)
Seek/W/R
340 350 500 6.6 6.7
Standby 7 7 185 1.0 1.0
Sleep 7 7 185 1.0 1.0
*1 Current is typical rms except for spin up.
*2 Power requirements reflect nominal values for +12V and +5V power.
*3 Idle mode is in effect when the drive is not reading, writing, seeking, or executing any commands. A portion of the
R/W circuitry is powered down, the spindle motor is up to speed and the Drive ready condition exists.
*4 R/W mode is defined as 50% read operations and 50% write operations on a single physical track.
*5 Seek/W/R mode is defined as 33% seek operations, 33% write operations and 33% read operations.
Typical Power (*2) [watts] Mode of Operation
