System configurator and order-information guide
B PRIMERGY TX100 S1 Status 2010-06-30
Section II Processor
One of following CPU´s has to be selected
for an orderable basic unit
Dual-Core CPU`s
- 1x 64-bit Intel
Core2 Duo Exx00 (2/3MB SLC) or
Xeon UP (4/6MB SLC)
with 1066 or 1333MHz Frontside Bus and heat pipe
occupies socket for one CPU
Pentium DC E5200 2.50GHz 2MB 800MHz FSB (65W) S26361-F3582-E520
Pentium DC E5400 2.70GHz 2MB 800MHz FSB (65W) S26361-F3582-E540
Pentium DC E6300 2.80GHz 2MB 1066MHz FSB (65W) S26361-F3582-E630
Pentium DC E6500 2.93GHz 2MB 1066MHz FSB (65W) S26361-F3582-E650
Core2 Duo E7400 2.80GHz 3MB 1066MHz FSB (65W) S26361-F3582-E740
Core2 Duo E7600 3.06GHz 3MB 1066MHz FSB (65W) S26361-F3582-E760
Xeon UP E3110 3.00GHz 6MB 1333MHz FSB (65W) S26361-F3503-E210
Xeon UP E3120 3.16GHz 6MB 1333MHz FSB (65W) S26361-F3503-E220
Quad-Core CPU`s
- 1x 64-bit Intel Xeon UP (6/8MB SLC = Second Level Cache on Chip )
with 1066 or 1333MHz Frontside Bus and heat pipe
occupies socket for one CPU
Xeon UP X3220 2.40GHz 2x4MB 1066MHz FSB (95W) S26361-F3504-E220
Xeon UP X3330 2.66GHz 6MB 1333MHz FSB (95W) S26361-F3504-E330
Section III Memory
There are 2 memory banks with 2 DIMM slots each.
Single channel memory configuration allow maximum flexibility:
Additional memory can be configured as single memory modules.
Dual channel memory configurations for maximum performance:
For optimum performance memory has to be configured in pairs of memory modules with identical size.
S26361-F3372-E413 S26361-F3372-E414
Main memory 1GB ECC Main memory 2GB ECC
DDR2 800/PC2-6400 unbuffered DDR2 800/PC2-6400 unbuffered
consisting of one module consisting of one module
max. 4x per system max. 4x per system
Section IV Graphics
ATI ES1000 (32MB) on board
S26361-F2748-E533
PY VGA Card 256MB PCI-e x1
NVIDIA Quadro NVS 290 The hight end optional NVIDIA NVS290 graphic card offers dual head operation
256 MB PCIe-x1 and fully 3D video support.
2x DVI or 2x VGA or The cables for either two times DVI or VGA connections are part of the delievery.
1x DVI plus 1x VGA
cables adapters included This PCIe-x1 card can also be installed in any PCIe-x4, x8 or x16 slot.
Dual head + fully 3-D Only one card per server is allowed.
supported for Windows OS
not supported for Linux OS (native) PY VGA card must be installed in slot 4
full height bracket
max. 1x per system S26361-F2748-L533
PY VGA card 256MB PCI-e x1
for loose delivery
C
Fujitsu Technology Solutions x86 PRIMERGY Server 8 of 13
