System configurator and order-information guide
D PRIMERGY TX100 S1 Status 2010-06-30
Section VI RAID-Controller
Section VII Hard disk drives
There is a 6 port SATA controller in the Base Unit.
Up to 4 SATA LFF (3.5") hard disks can be configured.
S26361-F3219-E160
HD 160GB 7.2krpm 3.5"
7200rpm,<9.0 ms, 8MB Cache
SATA 3Gb/s
non hot plug
max. 4x per system
S26361-F3334-E250 S26361-F3334-E500 S26361-F3334-E750 S26361-F3334-E100
HD 250GB 7.2krpm 3.5" HD 500GB 7.2krpm 3.5" HD 750GB 7.2krpm 3.5" HD 1000GB 7.2krpm 3.5"
4x 7200rpm,<9.0 ms, 8MB Cache 7200rpm,<9.0 ms, 8MB Cache 7200rpm,<9.0 ms, 8MB Cache 7200rpm,<9.0 ms, 8MB Cache
BC-SATA 3Gb/s BC-SATA 3Gb/s BC-SATA 3Gb/s BC-SATA 3Gb/s
non hot plug non hot plug non hot plug non hot plug
max. 4x per system max. 4x per system max. 4x per system max. 4x per system
E
Fujitsu Technology Solutions x86 PRIMERGY Server 10 of 13
