MB91401
42
(Continued)
Address
Register
Block
++++
0
++++
1
++++
2
++++
3
0540_0000
H
FIFO0out[R]
XXXXXXXX-XXXXXXXX
FIFO0in[W]
XXXXXXXX-XXXXXXXX
USB
0540_0004
H
FIFO1[R]
XXXXXXXX-XXXXXXXX
FIFO2[W]
XXXXXXXX-XXXXXXXX
0540_0008
H
FIFO3[W]
XXXXXXXX-XXXXXXXX


0540_000C
H
to
0540_001F
H
(Reserved)

0540_0020
H


CONT1[R/W]
XXXXX0XX-XXX00000
0540_0024
H
CONT2[R/W]
XXXXXXXX_XXX00000
CONT3[R/W]
XXXXXXXX_XXX00000
0540_0028
H
CONT4[R/W]
XXXXXXXX_XXX00000
CONT5[R/W]
XXXXXXXX_XXXX00XX
0540_002C
H
CONT6[R/W]
XXXXXXXX_XXXX00XX
CONT7[R/W]
XXXXXXXX_XXX00000
0540_0030
H
CONT8[R/W]
XXXXXXXX_XXX00000
CONT9[R/W]
XXXXXXXX_0XXX0000
0540_0034
H
CONT10[R/W]
XXXX0000_X000000X
TTSIZE[R/W]
00010001-00010001
0540_0038
H
TRSIZE[R/W]
00010001-00010001


0540_003C
H
to
0540_003F
H
(Reserved)

0540_0040
H
RSIZE0[R]
XXXXXXXX-XXXX0000


0540_0044
H
RSIZE1[R]
XXXXXXXX-X0000000


0540_0048
H
to
0540_005F
H
(Reserved)

USB
0540_0060
H


ST1[R/W]
XXXXXX00-00000000
0540_0064
H




