26
10. Press the [MENU] key. The SAVE confirmation window appears.
SAVE ?
YES
NO
CANCEL
SAVE confirmation window
11. With YES selected, press the [ENT] key to save the data.
4.3 System Settings
1. Press the [MENU] key to open the main menu.
2. Press the [6] key to open the SYSTEM SETTINGS sub-menu.
[SYSTEM SETTINGS]
1 SET I/O PORT
2 SET CHANNEL
3 SET LR MODE
4 SET OTHER I/O
5 SET BUZZER
SYSTEM SETTINGS sub-menu
3. Press the [1] key to display the SET I/O PORT sub-menu.
[SET I/O PORT]
1 I/O SPEED
2 I/O FUNCTION
3 I/O PRIORITY
4 SET LAN (IP ADDR)
SET I/O PORT sub-menu
4. Press the [1] key to display the I/O SPEED window.
[I/O SPEED]
LR
: 38.4 k
BCON : 4800
EXTRA1 : 38.4 k
XTRA I/O : 4800
1 2
+ -
+ -
+ -
+ -
[I/O SPEED]
PC I/O : 38.4 k
SNSR1 : 38.4 k
SNSR2 : 38.4 k
SNSR3 : 38.4 k
1 2
+ -
+ -
+ -
+ -
[NEXT] key
[SFT] +[NENT]
key
I/O SPEED window
