33
FURUNO
Model FE-700
Unit DISPLAY UNIT FE-701
DISTRIBUTION BOX FE-702
ELECTRICAL PARTS LIST Ref.Dwg. Page
Jan-99 Blk.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
02P6281,ANLG
001-229-240 FE-701 O
02P6282,MEM 001-229-220 FE-701 O
02P6283,CONE 001-229-030 FE-702 O
02P6280,MAIN 001-229-190 FE-701
PANEL ASSEMBLY
FE-701
001-229-370 w/PAL 02P6250 O
COVER
FE-701
001-229-340 O
POWER ASSEMBLY
FE-702
001-228-980 O
TRANSFORMER
T1 02S1256-0 000-142-779 FE-702
SWITCH
S1 M-2032L/B 000-474-351 FE-702
FILTER
FL1 ZCB2203-11 000-128-847 FE-702
FUSE HOLDER
FX1 FH043A 000-138-885 FE-702
FX2 FH043A 000-138-885 FE-702
TERMINAL BOARD
TB6 ML250S1AXF-3P 00-142-535 FE-702
TB7 ML250S1AXF-3P 00-142-535 FE-702
JACK
J1 MJ-A10SRMD 000-126-663
FUSE
F1 FGMB 1A 250V 000-142-771
F2 FGMB 1A 250V 000-142-771
