14
4 ECHO QUALITY SETTING
This chapter describes functions useful for
improving echo sounding performance.
4.1 Demonstration Display
The demonstration program shows how the
FE-700 works.
1. Turn off the equipment.
2. Press the POWER Switch while pressing any
key. Release the key when the following
EXTENSION MODE display appears.
EXTENSION MODE
+ : TRANSDUCER SETTING
- : TEST
▲ : CLEAR MEMORY
▼ : DEMONSTRATION
SELECT MODE
3. Press the [▼] key to select
DEMONSTRATION.
DEMONSTRATION
OFF ON
-/+:
To set option
▼: EXTENSION MODE
4. Press the [+] key to select ON.
5. Reset the power. "DEMO" appears above
the depth indication on the echo sounder
displays and at the top right-hand corner on
the data and graphic displays.
! To return to the normal operation, select
OFF at step 4 above. Restart the display unit
after waiting 5 s.
4.2 Transducer Setting
After installing the equipment, set the transducer
as follows.
1. Press the [+] key at the EXTENSION MODE
display. The following window appears.
TRANSDUCER SETTING
XDR FORE N/A 50kHz 200kHz
XDR AFT N/A 50kHz 200kHz
▼▲
: To select item
- +: To set option
2. Set as follows by using [▲] or [▼] to select
an item and [+] or[-] to set option.
a) If only one transducer is installed, set
XDR FORE field to 50 kHz or 200 kHz,
according to actual installation. Leave the
XDR AFT field as “N/A.”
b) If two transducers are installed via the
switch box EX-8, set XDR FORE field and
XDR AFT field to 50 kHz or 200 kHz,
according to actual installation.
3. Reset the power.
Note: The default settings in the TRANSDUCER
SETTING window are N/A. At the first power-up
after installation, the window appears to set
transducer(s).
