17
5.2 Menu Operation
5.2.1 Dimmer control
The dimmer is controlled either with the DIM key,
or the optional Dimmer Controller. The method of
control must be selected on the menu.
1. Press the MENU key to display the main
menu.
MENU
DIM CONTROL
PANEL ONLY
/LANG. ENGLISH
UNITS m
ALARM SET ON
TEST
2. Press [▲] or [▼] to select DIM CONTROL.
3. Press the ENT key. The following window
appears.
MENU
DIM CONTROL
PANEL ONLY
/LANG. PANEL ONLY
UNITS EXT CONTROLLER
ALARM SET EXT DISP
TEST
4. Press [▲] or [▼] to select option desired.
PANEL ONLY: The illumination of the control
panel is adjusted with the DIM key.
EXT CONTROLLER: Illumination of control
panel is adjusted with the optional dimmer
controller (hand dimmer box). The DIM key is
inoperative.
EXT DISP: Not used.
5. Press the ENT key to set.
6. Press the MENU key to finish.
5.2.2 Selecting language
The language in use on the screen is either
English or Japanese.
1. Press the MENU key to display main menu.
2. Press [▲] or [▼] to select the /LANG.
3. Press the ENT key. The following window
appears.
ENGLISH
4. Press [▲] or [▼] to select appropriate option.
The default is English.
5. Press the ENT key to set.
6. Press the MENU key to finish.
5.2.3 Selecting the unit of depth
measurement
The unit of depth measurement is separately
selected from the Main Display FE-701.
1. Press the MENU key to display main menu.
2. Press [▲] or [▼] to select the UNITS.
3. Press the ENT key. The following window
appears.
m
ft
fa
4. Press [▲] or [▼] to select unit.
The default is meter (m).
5. Press the ENT key to set.
6. Press the MENU key to finish.
