1. OPERATIONAL OVERVIEW
1-11
1.5.3 Switching control in combination and overlay screens
A soft key is provided in relevant combination and overlay screens to switch
control between displays. In the example below, the PLOTTR CNTRL and SNDR
CNTRL soft keys enable switching control between the plotter and sounder
screens in the plotter/sounder combination display.
To adjust
sounder
PLOTTR
CNTRL
To adjust
plotter
SNDR
CNTRL
Plotter display selected
FISH WP-002
MARK
ENTRY
PLOTTR
CNTRL
NAV
POS
MODE
NTH UP
16.0nm 40.0
97
150
200
50
100
0 0’33"
50k
Sounder display selected
FISH WP-002
MODE
SNDR
CNTRL
FREQ
50 /200
16.0nm
40.0
97
150
200
50
100
0 0’33"
50k
DISPLAY
MODE
SHIFT
34 ° 22. 3456’N 359.9 ° M TRIP NU
080 ° 22. 3456’E 19.9 kt 99.9 nm
34 ° 22. 3456’N 359.9 ° M TRIP NU
080 ° 22. 3456’E 19.9 kt 99.9 nm
How to switch control between modes in the plotter/sounder combination display
