3. PLOTTER OPERATION
3-39
6. Choose how to record points for your route, by time, by range or manual
entry, by pressing BCKTRK TIME, BCKTRK RANGE or MANUAL soft key as
appropriate. For manual entry, go to step 8. For BCKTRK TIME, BCKTRK
DIST one of the following displays appears.
0 0h01m
(When selecting BCKTRK TIME.)
0 0.1nm
(When selecting BCKTRK DIST.)
TIME INTERVALDISTANCE INTERVAL
Displays for entry of time, distance interval
7. Enter interval desired with the trackball and the alphanumeric keys. Press the
START LOG and RETURN soft keys followed by the [MENU] key to close the
menu. At this moment, a voyage-based route will be created.
8. For manual entry of waypoints, do the following:
a) Press the [SAVE/MOB] key momentarily to enter a waypoint mark at own
ship position. A new waypoint is created under the youngest empty
waypoint number and added to the route. (At this time you may close the
SAVE ROUTE screen by pressing the RETURN soft key followed by the
[MENU] key.)
b) Repeat step a) as necessary. 35 waypoints may be entered.
To stop recording waypoints and save the route
You can stop recording waypoints and save the route as shown in the procedure
below. When 35 waypoints have been entered the message “Total 35 WPTS
have been already registered in the route. Stop creating voyage-based route.” is
displayed. In this case, automatically creating voyage-based route stops.
1. Press the [MENU] key followed by the WAYPOINTS/ROUTES and CREATE
VOYAGE-BASED ROUTE soft keys.
2. Press the FINISH LOG soft key to stop recording waypoints and save the
route.
3. Press the [MENU] key to close the menu.
