Ⅵ Model name/Article name FDP-DILA3 THEATER OPTIMIZED PACKAGE
Ⅵ Emission method
D-ILA
®
* (Reflective Active Matrix Principle)
Ⅵ Display panel/ size
D-ILA /0.7 (1400pixels x 1050pixels) x 3 (Total number of pixels: 4,410,000)
Ⅵ Projecting lens x 1.3 zoom lens (2.1: ~2.6:1) (Manual zooming and focusing)
Ⅵ Light-source lamp
250W Ultra High Pressure Mercury lamp
[Part No.: BHL5006-S/Rating: 250W]
Ⅵ Screen size 40 ~ 200
Ⅵ Projection distance Approx. 1.6m ~ 12m
Ⅵ Color system NTSC/PAL via external Video Processor
Ⅵ Resolution
1400 dots x 1050 dots (S-XGA full resolution, during RGB input)
1000 TV lines (Horizontal resolution, aspect ratio 4:3, during video input)
Ⅵ Scanning frequency
Horizontal frequency : 15kHz~120kHz
Vertical frequency
: 50Hz~120Hz
Ⅵ Input terminals VIDEO IN
Y/C
1-line, mini DIN 4 pin x 1
Y: 1.0 Vp-p, 75ohm C:0. 286 Vp-p, 75ohm(NTSC), 0.3Vp-p, 75ohm(PAL)
VIDEO
1-line, RCA pin x 1
1.0V(p-p),75ohm,synchronised
PC 1
1-line, D-sub 3-rows 15 pin x 1
PC 2
1-line, BNC x 5
Y, CB,CR : Component (Y, B-Y, R-Y) signal (Color Difference signal)
Y, PB, PR : DTV-format (Y, P
B
, P
R
) signal
R, G, B
: Analog RGB signal
H/Cs, V
: Horizontal (H) sync/composite (Cs) sync, Vertical (V) sync signal
PC3
1-line, DVI-D (single-24pin) terminal
AUDIO
1-line, RCApin X 1 (Y/C, VIDEO, PC1, PC2, PC3) 0.5V(rms), high impedance
CONTROL
RS-232C : 1-line, D-sub 9pin x1 (External controller)
REMOTE : 1-line, stereo mini-jack x1 (remote control)
Ⅵ Output terminals
DC OUT 5V, 1.5A DC Power Jack
Ⅵ Power requirements
AC 100V ~ 240V AC, 50Hz/ 60Hz
Ⅵ Power consumption
3.4 A (100V AC) ~ 1.42A (240V AC)
Ⅵ Operation environment
Temperature: 41°F ~ 95°F (+5°C ~ +35°C)
Humidity: 20% ~ 80% (no condensation.)
(Preservation temperature 14°F ~ 140°F (–10°C ~ +60°C))
Ⅵ Dimensions (Width x Height x Length) Approx. 16.57” x approx. 6.67” x approx. 18.8”
Ⅵ Mass Approx. 28.0lbs
Specifications
• D-ILA
®
is the abbreviation for Direct drive Image Light Amplifier.
• Design and Specifications are subject to change without notice.
• D-ILA
®
devices are manufactured with a very high-precision technology. Pixel effectiveness is 99.99%. Only 0.01% or less of the
pixels would either not light up or remain permanently lighted up.
• For easy understanding, pictures and illustrations may be emphasized, composed or have omissions and may be more or less
different from the actual products.
• All brand names and products (IBM, Macintosh) herein are the trademarks or registered trademarks of their respective compa-
nies.
• This product conforms to the ‘Household electric appliances and general-purpose articles harmonics control measure guideline.’
