Parts List
13
1
•
XG1200
The XG1200 itself (from zero to eight Xenpak modules may
be installed).
•
Power Cord
A 3-pin cable to connect the XG1200 to a power supply.
•
Serial Cross Cable
A cable to connect the XG1200 to a PC when the settings
need to be adjusted.
•
Rack Mounting Bracket L
A bracket for mounting the XG1200 in a rack. Attach the rack
mounting bracket L to the front-left side of the XG1200, and
fasten to the front-left rack post with the rack screws (large).
•
Rack Mounting Bracket R A bracket for mounting the XG1200 in a rack. Attach the rack
mounting bracket R to the front-right side of the XG1200, and
fasten to the front-right rack post with the rack screws (large).
•
Rack Mounting Bracket BL A bracket for mounting the XG1200 in a rack. Attach the rack
mounting bracket BL to the back-left side of the XG1200, and
fasten to the rail (attached to the back-left rack post) with the
rack screws (small).
•
Rack Mounting Bracket BR A bracket for mounting the XG1200 in a rack. Attach the rack
mounting bracket BR to the back-right side of the XG1200,
and fasten to the rail (attached to the back-right rack post)
with the rack screws (small).
•
Rails
Two rails that are attached to the back-left and back-right
rack posts and into which the back rack mounting brackets
(BL, BR) are slid and then fastened when mounting the
XG1200 in a rack.
•
Bracket Screws
Countersunk screws for fixing the rack mounting brackets (L,
R, BL, and BR) to the XG1200.
•
Rack Nuts
When the rack post holes are round, use the rack nuts to fas-
ten the XG1200 and the rails to the rack posts with the rack
screws (large).
•
Cage Nuts
When the rack post holes are square, use the rack nuts to
fasten the XG1200 and the rails to the rack posts with the
rack screws (large).
•
Rack Screws (Large)
Pan-head screws for fixing the XG1200 and the rails to the
rack posts.
•
Rack Screws (Small)
Pan-head screws for fixing the back rack mounting brackets
(BL, BR) to the rails.
•
CD-ROM
Contains documents necessary to operate the XG1200.
•
Hardware Guide
A manual describing the XG1200 hardware and related mat-
ters (this manual).
•
Wrist Strap
Used when performing maintenance on the XG1200.
