ASSEMBLY
• Place a 3 /
8
" (0,95 cm) -16 lock nut (rounded side out)
onto a front axle.
IMPORTANT: Tighten the lock nut firmly using the closed
end of the assembly tool.
• Repeat this procedure to fasten the other front wheel
assembly with the other 3 /
8
" (0,95 cm) -16 lock nut.
3 / 8 " (0,95 cm) -16 Lock Nut
Assembly Tool
• Align the slot in a hubcap with the rib in the wheel cover.
"Snap" a hubcap into the center of each wheel cover.
Wheel
Cover
Hubcap
4
5
• Fit the front end onto the vehicle.
• Insert the tabs on the back edge of the front end into the
slots in the vehicle.
Front End
• Insert two #8 x
3
/
4
" (1,9 cm) screws through the front end
and into the vehicle. Tighten the screws.
#8 x
3
/
4
" (1,9 cm) Screws
