ASSEMBLY
• Fit the large hole on the plates to the door posts.
• Align the holes in the plates with the holes in the top side
of the vehicle.
Plates
16
• Fit the door pegs onto the holes near the front end of
the vehicle.
Hint: There is a left and right door. They are designed to be
assembled one way.
15
• Insert one #8 x
3
/
4
" (1,9 cm) screw into the top edge of
each headlight. Tighten the screws.
14
#8 x
3
/
4
" (1,9 cm) Screws
• Fit the headlights (left and right) onto the bumper.
Hint: Headlights only fit one way. If they do not seem to fit,
try the other side.
Headlights
13
Doors
