VR800 Owner’s Manual (Punch In/Out Recording)
When you finish storing and adjusting the respective edit points, you can proceed to the Auto Punch In/Out
operations. In this example, we will re-record part of the guitar phrase on track 3, chosen from all the recordings
on tracks 1-8. Prior to proceeding with this operation, check to see that an external digiral mixer is connected to
VR800 as shown in the figure. then confirm that the guitar to record on track 3 is connected to the input jack of
the digital mixer.
