VR800 Owner's Manual (Maintenance/Specifications)
118
Specifications
Input/Output
Connector : Optical (X 2)
Format : (1) IEC 60958 (S/P DIF)
: (2) Alesis Proprietary Multi
Channel Optical Interface (Adat
optical)
(Either (1) or (2) is selected in the
Setup mode.)
Connector : DIN 5PIN (X 2)
Format : MIDI standard
Connector :D-sub 25 pin (X1)
Protocol : SCSI-2, unbalanced transmission
format
Transmission format : Asynchronous transmission
Units connected
: Two
SCSI-ID : Automatic recognition
Connector : BNC (X 1)
Output level : TTL level
Load impedance : 75Ω
Connector : ø6mm Phone jack (X 1)
(An optional FOOT SW Model 8051
can be connected.)
Recording/Reproducing
:3.5 inch, hard disk (E-IDE type)
:External SCSI device (SCSI-2, unbalanced
transmission format)
: FDMS-3*
:ADAC 8ch mode:
8 real tracks+16 additional tracks
(44.1kHz/A.D.A.C.)
:Master 8ch mode:
8 real tracks+16 additional tracks
(44.1kHz/16bit linear)
:Master 4ch mode:
4 real tracks+20 additional tracks
(44.1kHz/16bit linear)
:ADAC 8ch mode: SCSI
:Master 8ch mode: FDIO-1 (DAT, adat), SCSI
:Master 4ch mode: SCSI, FDIO-1 (DAT)
: 20-bit 64-time, over sampling, Delta-Sigma
: 20-bit 128-time, over sampling, Delta-Sigma
: maximum 99 tunes
:8 tracks (Master 8ch/ADAC 8ch mode)
:4 tracks (Master 4ch mode)
: +/-6%
: 44.1kHz/16bit linear
General
Dimensions : 254 (W) X 100 (H) X 285 (D) mm
* Including highest protrusion.
Weight : approx. 2.0kg
Power supply : 120VAC 60Hz
: 230V~ 50/60Hz
Power consumption : approx. 15W
* Specifications and appearance are subject to change
without notice for product improvement.
* "Adat" and the
OPTICAL
symbol are trademarks of Alesis
Corporation.
* FDMS-3: Fostex Disk Management System-3.
* FDIO-1 Ver.2: Fostex Data In Out-1 Ver.2
Maintenance
Cleaning the exterior
* For normal cleaning, use a soft dry cloth.
For stubborn dirt, moisten a cloth in diluted detergent, wring it out firmly, and wipe the dirt off.
Then polish with a dry cloth. Never use solvents such as alcohol, thinner or benzene, since these will damage the
printing and finish of the exterior.
