FS-100 Portable DTE Recorder
67
In addition to setting VFR MODE to the
Base Frame Rate
, a
PN DTE
format must be selected from the
FS-100 DV FORMAT
menu, see
VFR MODE is inactive for non-PN DV FORMATS.
Set AG-HVX200 to Standard Record Mode
The Panasonic AG-HVX200 must be set to standard record
mode or 720P mode but not 720PN.
FS-100 VFR MODE supports three stream types:
• 720/24P and 720/30P on 60 Hz systems.
• 720/30P on 50 Hz systems.
On the AG-HVX200:
1.
Set
SCENE FILE > OPERATION TYPE
to
FILM CAM
.
2.
Set
RECORD SETUP > UB MODE
to
FRM. RATE
.
3.
Set
SCENE FILE > FRAME RATE
to the desired
Incoming
Frame Rate
.
See the AG-HVX200 manual for more information.
When recording, the FS-100 Home screen displays
VF
on the
right, below the battery level indicator.
During playback, the
VF
indicator is not available and
PN
is
displayed.
REC
COUNTER
00:00:14:02 VF
DISK 1 168 min
REEL
TAPE DISP LOCK
