8
Ethernet Cable: Crossover Pinout
The following is the proper pin out and cable pair/color order for the "crossover" end.
orange Pin 6 wire color:
white/orange Pin 3 wire color:
Pair#3 is connected to pins 3 and 6 like this:
green Pin 2 wire color:
white/green Pin 1 wire color:
Pair#2 is connected to pins 1 and 2 like this:
