* Distance Signal Travels at 100 Mbits?
Name
Transmission Medium
Data Rate
(Mb/s)
Distance
(m)
100BASE-TX 2
pairs
of
Category
UTP-5,
alternative 2 pairs of STP, 150 Ω
Impedance, Cable Code MLT-3,
Full Duplex
100
100
100BASE-FX 2 Multimode Optical Fiber (62.5/125
µm), Cable Code 4B5B, NRZI, Full
Duplex
100
2,000
100BASE-T4 4 pairs of Category 3 UTP-(3/4/5) or
better, 100 Ω Impedance, Cable
Code 8B6T, No Full Duplex
100
100
100BASE-T2 2 pairs of Category 3 UTP-(3/4/5) or
better, Cable Code PAM5, Full
Duplex
100
100
Supported by M
CF5223x
Requires using external PHY
