Chassis Identification
The following figures show the physical characteristics of the SPARC Enterprise
T2000 server.
FIGURE 3 SPARC Enterprise T2000 Server Front Panel
FIGURE 4 SPARC Enterprise T2000 Server Rear Panel
For details on how to install the server refer to the SPARC Enterprise T2000 Server
Installation Guide.
Hard drives
DVD drive
HDD0
Indicators and buttons
HDD2
HDD1
HDD3
2
3
USB ports
Power supply 0 Power supply 1
PCI Express
SC serial mgt
SC net mgt
Indicators
PCI Express
PCI-X slot 1
PCI-X slot 0
TTYA serial
GBE ports
2
0
1
3
0
1
USB ports
port
PCI Express
port
port
slot 2
slot 1 slot 0
