FS-8700-132 Gamewell FCI-E3 Driver Manual

Page 8 of 20

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

5.3.2 Driver Related Map Descriptor Parameters

Column Title

Function

Legal Values

Node_Name

Name of Node to fetch data from

One of the Node
Names specified in
Section 5.2

Event Type*

This driver uses this parameter to determine the suitability of a Map
Descriptor when looking for a location to store data from an
incoming message.
A Map Descriptor may be defined to store only ‘Alarm’, ‘Fault’,
‘Trouble’ or ‘Other events. Alternatively, specify “Any”
A table of events vs. categories is provided in Appendix C.1

Any, Other, Fault,
Alarm, Trouble

Point Type

This driver uses this parameter to determine the suitability of a Map
Descriptor when looking for a location to store data from an
incoming message.

Zone, Relay, Loop,
Sensor,

Module,

Panel

Relay/Loop/Zone
Number

Ignored when the Point Type is ‘Panel’
Point Type = Relay 1..255
Point Type = Zone 1..8
Point Type = Loop 1..2
Point Type = Module 1..2
Point Type = Sensor 1..2

Whole Numbers
1, 2 , etc

Length*

Each Map Descriptor defines storage locations for a series of
addresses. This parameter specifies the length of the series.

1,2,3 .etc
Whole numbers

Address

This parameter is specific to Map Descriptors with ‘Event Type’
Module or Sensor. It specifies the starting Module or Sensor
number. The length parameter then determines the range of the
Sensor/Module numbers

1..99

Store As*

If set to ‘Bit’ the driver will use the primary Data Array to store using
the ‘Bit Storage’ Method. These methods are described in Appendix
A.1

Bit, Index_Value

DA_Bit_Name

If the default ‘Store As’ is specified or if the parameter is omitted
then a secondary array can be specified using this parameter - the
driver will store event data as ‘Bit Storage’ in the Secondary array
(and as ‘Index Values’ in the Primary array.) These methods are
described in Appendix A.1

One of the Data
Array

names

Specified

under

Section 4

Clear on Reset*

If this parameter is specified it will prevent the Driver resetting the
Data Array points associated with the Map Descriptor on reset.

Yes, No
