FS-8700-132 Gamewell FCI-E3 Driver Manual

Page 10 of 20

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

5.5

Map Descriptor Example 2 – Bit Storage

This example defines storage location for Relay Point events. The example would work for all other point types. In the example, both primary and secondary storage Data
Arrays have been specified. The driver stores index values in the primary array. Each new event for a particular relay will overwrite the value stored previously. In the Bit
Array, the driver sets the bit corresponding to the event, leaving other bits unchanged – thus the secondary storage can be used to determine if more than one event is
active at a time.

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , DA_Bit_Name , Function

, Node_Name , Event Type , Point Type , Relay/Loop/Zone Number , Address , Length , Clear_on_Reset

RelayData

, DA_RELAY

, 0

, DB_Relay

, Passive_Client , Panel-01

, Any

, Relay

, 1

, -

, 4

, Yes

Map Descriptors for
storing Relay, Loop, Zone
and Panel do not need the
address specified.

Data_Array_Name is where the
primary DA is specified. Index
values are stored here

DA_Bit_Name is where secondary storage is
defined. Events are stored by setting appropriate
bits.
Remember that 2 elements per Relay, Module,
Sensor, Loop are used.
