FS-8700-132 Gamewell FCI-E3 Driver Manual Page 19 of 20
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix C.4. Driver Stats Exposed.
In addition to the standard FieldServer operating statistics the driver exposes certain key stats in a Data Array if
required. An upstream device can then monitor these stats.
Add the following to the configuration file to activate these stats.
// Expose Driver Operating Stats.
Data_Arrays
Data_Array_Name , Data_Format , Data_Array_Length
fci-e3-stats
, UINT32 , 200
The driver exposes stats based on a port handle. The offset specified in the table below must be added to the
handle number multiplied by 100. i.e. for port whose handle is 1 then the driver will store the 1
st
stat at
1+100*1=101.
Stat Offset Description
FCI_E3_STAT_NO_PLACE_TO_STORE 1
Increments each time point data is received but there
is no Map Descriptor to store the data (any)
FCI_E3_STAT_NO_PLACE_TO_STORE_ZONE 2
Increments each time point data is received but there
is no Map Descriptor to store Zone data
FCI_E3_STAT_NO_PLACE_TO_STORE_RELAY 3
Increments each time point data is received but there
is no Map Descriptor to store Relay data
FCI_E3_STAT_NO_PLACE_TO_STORE_LOOP 4
Increments each time point data is received but there
is no Map Descriptor to store the Loop data
FCI_E3_STAT_NO_PLACE_TO_STORE_SENSOR 5
Increments each time point data is received but there
is no Map Descriptor to store the Sensor data
FCI_E3_STAT_NO_PLACE_TO_STORE_MODULE 6
Increments each time point data is received but there
is no Map Descriptor to store the Module data
FCI_E3_STAT_EMPTY_MSG 7
Number of times that a message line was zero bytes
long (excluding the terminator)
FCI_E3_STAT_SHORT_MSG 8
Number of times that a message line was too short
probably a system id tag line
FCI_E3_STAT_NO_RESET 9
Increments each time a reset was rcvd but no Data
Array was reset
FCI_E3_STAT_NO_PLACE_TO_STORE_PANEL 10
Increments each time point data is received but there
is no Map Descriptor to store data that cannot be
attributed to a zone, relay, loop, sensor, module
FCI_E3_STAT_RCVD_MSGS 11 Increments each time a message is received
FCI_E3_STAT_RCVD_BYTES 12
Increments each time a character is received from the
panel. The bytes are only added when a message
terminator is received. Thus this count is equivalent to
the byte count in all FCI_E3_STAT_RCVD_MSGS
FCI_E3_STAT_PARSED_NO_ERRS_EXCLD_RESET 13
Increments each time a message is parsed without
errors. Excludes Reset Messages
FCI_E3_STAT_PARSED_NO_ERRS_RESET 14
Increments each time a reset message is parsed
without errors.
