Fisher-Price 74260 - Manual (Page 19)

19
Assembly
30
• Using safety scissors, separate the wheel bushings and
the spacer from the plastic connectors. Dispose of the
plastic connectors properly.
• Fit two wheel bushings into the center opening in the
front wheel, as shown.
Front Wheel
Wheel
Bushing
Wheel
Bushing
• With the speaker side down, fit the sound box into the
opening in the pony head.
28
• Fit and hold the pony face against the pony head.
• Insert three #8 x 1" truss head shoulder screws through
the holes in the pony face and into the pony head.
• Tighten the screws with a Phillips screwdriver.
Do not over-tighten.
• Set the pony head assembly aside.
29
Pony Head
Pony Face
Sound
Box
Pony Head
• Fit the two spacers into the center opening in the front
wheel, as shown.
• Insert a #8 x 3 /
4
" screw into the hole in the each spacer.
• Tighten the screw with a Phillips screwdriver.
Do not over-tighten.
31
Front Wheel
Spacer
(with screw hole
completely through)
Spacer
