Page 73: 32 a single-phase 5-way socket strip
73
Power Distribution
7.3
Installing the socket strips
7.3.1
32 A single-phase 5-way socket strip
Introduction
I
For more information, see the configurator:
Figure 41: 32 A single-phase 5-way socket strip
Required tools
The following tools are required to perform this task:
–
Torx screwdriver
No. of sockets 10 A
No. of sockets 16 A
Type of plug
Max. current
2x IEC 60320 C13
3x IEC 60320 C19
blue 32 A IEC 60309
(1-phase)
32 A
