Cable cut-out at the lower rear door
A cable cut-out ( so-called "cat door") can be found at the lower end of the right
rear door (see following figure). To install the cat door proceed as follows:
Figure 17: Cover for the cable cut-out at the lower rear door
Ê Unscrew the 5 screws that fix the cover for the cat door.
Ê Confect two edge protectors (length: 70 mm (2)) from the edge protector
oval (1).
/
