XStar ® Parts List (continued)
6
REF NO. PART NO. DESCRIPTION EQ
08
M
11
-A
EQ
08
M
11
-B
XQ
05
M
10
-A
XQ
05
M
10
-B
XQ
06
M
10
-A
XQ
08
M
10
-A
XQ
08
M
10
-B
XQ
10
M
10
-A
19 61776903 MOTOR MOUNT 1 1 1 1 1 1 1 1
20 61619517 COVER TOP Q-CHASSIS VENTED 1 1 1 1 1 1 1 1
21 91400400 COMPRESSOR MOUNTING BOLT 3 3 3 3 3 3 3 3
22 61028900 COMPRESSOR GROMMET 3 3 3 3 3 3 3 3
23 61638400 DRAIN PAN 1 1 1 1 1 1 1 1
24 61626312 BASEPAN 1 1 1 1 1
24 61626313 BASEPAN 1
24 61626314 BASEPAN 1 1
25 61625813 SHELL ASY CHASSIS S/W Q VENTED 1 1 1 1 1 1 1 1
26 61627211 CHANNEL SILL Q CHASSIS 1 1 1 1 1 1 1 1
27 61627313 SUPPORT TOP BRACKET/CHANNEL Q 1 1 1 1 1 1
28 61637717 DECORATIVE FRONT 1 1 1 1 1 1 1 1
29 61632315 AIR FILTER 1 1 1 1 1 1 1 1
30 61680205 ASY CURTAIN AND FRAME Q 1 1 1 1 1 1
31 61717300 GASKET CHASSIS SEAL Q 1 1 1 1 1 1 1 1
* 61715800 COUNTER WEIGHT 6 6 3 3 3 3 6 2
* 61883101 ISOLATION PAD 1
* 61699801 DEFROST THERMOSTAT 1 1
* 61699901 CLIP (FOR DEFROST THERMOSTAT) 1 1
* 60179903 CONDENSATE VALVE 1 1
* 61834800 STRAINER 1 1 1 1 1 1 1 1
* 61947500 DUCT DISCHARGE EQ 1 1
* 61911605 CONTROL KNOBS 2 2
* 60062720 CAPACITOR STRAP 1 1 1 1 1 1 1 1
* 61619405 DECK (EQ08) 1 1
* 61990500 DECK, EVAP Q CHASSIS 1 1 1 1 1 1
* 60217902 SEAL FAN MOTOR TO INNER WALL 1 1 1 1 1 1 1 1
* 60301800 WIRE CLIP FASTEX 1 1 1 1 1 1 1 1
* 91500306 CLAMP COATED ROUND 14AWG 1 1 1 1 1 1 1 1
* 61619612 CONTROL MOUNTING BRACKET 1 1
* 61715922 CONTROL DECORATIVE PLATE/PANEL 1 1
* 25066200 WIRE INSULATOR STR-LG 3 3
* 61900500 HOLDER T-STAT SENSOR 1 1
* 61925001 HOLDER, THERMISTOR 1 1 1 1 1 1
* 61031040 GASKET 2 2 2 2 2 2 2 2
* 60169120 SCRIPT FRIEDRICH 2010 "FESTOON" 1 1 1 1 1 1 1 1
* 91002900 SPEEDNUT PUSH TYPE 3 3 3 2 3 3 3 3
* 61031049 GASKET,FOAM PLSTC PRESS/SENS 1 1 1 1 1 1
* 61778700 BAG ASY PLSTC SQ-KQ-XQ 1 1 1 1 1 1
* 61778701 BAG ASY PLSTC YQ & EQ08 1 1
* 60073300 GASKET URETHANE FOAM 1 1 1 1 1 1
* 01900235 DC-2 DRAIN KIT
* 01109003 TOUCH UP SPRAY PAINT (12 OZ.)
