Kühl Small chassis Parts List
9
REF NO. PART NO. DESCRIPTION ES
12
M
33
-A
ES
12
M
33
-B
ES
15
M
33
-A
SS
08
M
10
-A
SS
10
M
10
-A
SS
10
M
10
-B
SS
12
M
10
-A
SS
12
M
30
-A
SS
12
M
30
-B
SS
14
M
10
-A
SS
15
M
30
-A
YS
10
M
10
-A
YS
12
M
33
-A
1 61850323 CONDENSER COIL 1 1 1 1 1 1 1 1 1 1 1
1 61850340 CONDENSER COIL 1
1 62050304 CONDENSER COIL 1
2 61850110 EVAPORATOR COIL 1 1 1 1 1 1
2 61850117 EVAPORATOR COIL 1
2 61850118 EVAPORATOR COIL 1
2 61850123 EVAPORATOR COIL 1 1
2 62050032 EVAPORATOR COIL 1 1 1
3 61717102 COMPRESSOR KIT 1
3 61717115 COMPRESSOR KIT 1 1
3 61717120 COMPRESSOR KIT 1
3 61717116 COMPRESSOR KIT 1
3 61717127 COMPRESSOR KIT 1 1
3 61717126 COMPRESSOR KIT 1
3 61717152 COMPRESSOR KIT 1
3 61717164 COMPRESSOR KIT 1 1
3 61717176 COMPRESSOR KIT 1 1
4 25022032 REVERSING VALVE + SOLENOID KIT 1
4 25022022 REVERSING VALVE + SOLENOID KIT 1
* 61824405 CHECK VALVE 1 1
* 03760500 CAPILLARY TUBE 1
* 03760517 CAPILLARY TUBE 1
* 03760482 CAPILLARY TUBE 1
* 03760548 CAPILLARY TUBE 1 1
* 03760473 CAPILLARY TUBE 1
* 03760479 CAPILLARY TUBE 1
* 03760555 CAPILLARY TUBE 1
* 03760520 CAPILLARY TUBE 1 1 1 1
* 03760555 CAPILLARY TUBE 1
* 03760511 CAPILLARY TUBE 1 1
* 61828202 LIQUID DRIER 1 1 1 1 1 1 1 1 1 1 1
* 61828204 SUCTION DRIER 1 1
5 62601006 ELECTRONIC CTRL USER INTERFACE KIT 1 1 1 1 1 1 1 1 1 1 1 1 1
6 62601000 ELECTRONIC CTRL (COOL ONLY KIT) 1 1 1 1 1 1 1 1
6 62601003 ELECTRONIC CTRL (ELEC. HEAT + COOL KIT) 1 1 1
6 62601002 ELECTRONIC CTRL (HEAT PUMP + ELEC. HEAT KIT) 1
6 62601004 ELECTRONIC CTRL (HEAT PUMP + COOL KIT) 1
* 62601007 THERMISTOR ASY FOR ELEC. CTRL. 1 1 1 1 1 1 1 1 1 1 1 1 1
* 62601005 REMOTE CONTROL KIT 2010 1 1 1 1 1 1 1 1 1 1 1 1 1
7 61080522 CAPACITOR 1 1
7 61080529 CAPACITOR 1
7 61080532 CAPACITOR 1 1
7 61080533 CAPACITOR 1
7 61080536 CAPACITOR 1 1
7 61080559 CAPACITOR 1 1
7 61080569 CAPACITOR 1
7 61080582 CAPACITOR 1 1
8 25063605 SOLENOID COIL 1
8 25063505 SOLENOID COIL 1
9 61717126 COMPRESSOR KIT 1
9 61764558 OVERLOAD 1
9 61764565 OVERLOAD 1 1
9 61764566 OVERLOAD 1
9 61764583 OVERLOAD 1
9 61764584 OVERLOAD 1
9 61764585 OVERLOAD 1 1
9 61764586 OVERLOAD 1 1
9 61764589 OVERLOAD 1
9 61764594 OVERLOAD 1 1
10 61878610 HEATER 3.3 KW @ 230V 1 1 1 1
