Kühl Medium chassis Parts List
11
REF NO. PART NO. DESCRIPTION EM
18
M
34
-A
EM
24
M
34
-A
SM
18
M
30
-A
SM
21
M
30
-A
SM
24
M
30
-A
YM
18
M
34
-A
1 61850227 CONDENSER COIL 1 1 1
1 61850228 CONDENSER COIL 1 1 1
2 61850108 EVAPORATOR COIL 1 1 1
2 62050030 EVAPORATOR COIL 1
2 62050034 EVAPORATOR COIL 1 1
3 61717118 COMPRESSOR KIT 1
3 61717119 COMPRESSOR KIT 1
3 61717131 COMPRESSOR KIT 1 1
3 61717121 COMPRESSOR KIT 1 1
4 25022032 REVERSING VALVE + SOLENOID KIT 1
* 61824405 CHECK VALVE 1
* 03760500 CAPILLARY TUBE 1
* 03760501 CAPILLARY TUBE 1
* 03760513 CAPILLARY TUBE 2 2
* 03760545 CAPILLARY TUBE 3 3
* 03760451 CAPILLARY TUBE 1
* 61828202 LIQUID DRIER 1 1
* 61828203 LIQUID DRIER 1 1 1
* 61828204 SUCTION DRIER 1
5 62601006 ELECTRONIC CTRL USER INTERFACE KIT 1 1 1 1 1 1
6 62601000 ELECTRONIC CTRL (COOL ONLY KIT) 1 1 1
6 62601003 ELECTRONIC CTRL (ELEC. HEAT + COOL KIT) 1 1
6 62601002 ELECTRONIC CTRL (HEAT PUMP + ELEC. HEAT KIT) 1
* 62601007 THERMISTOR ASY FOR ELEC. CTRL. 1 1 1 1 1 1
* 62601005 REMOTE CONTROL KIT 2010 1 1 1 1 1 1
7 61080529 CAPACITOR 1 1 1
7 61080557 CAPACITOR 1 1
7 61080570 CAPACITOR 1
8 25063605 SOLENOID COIL 1
10 61878611 HEATER 4.0 KW @ 230V 1 1 1
11 61871432 FAN MOTOR 1 1 1 1 1 1
12 60500394 SUPPLY CORD 1 1
12 60500398 SUPPLY CORD 1
12 60500399 SUPPLY CORD 1 1 1
13 60179903 BELLOWS CONDENSATE VALVE 1 1 1
14 60610616 BLOWER WHEEL, EVAPORATOR 1 1
14 60610617 BLOWER WHEEL, EVAPORATOR 1 1
14 60610618 BLOWER WHEEL, EVAPORATOR 1 1
15 61817505 SCROLL MEDIUM 1 1 1 1 1 1
16 60542004 FAN BLADE, CONDENSER 1 1 1 1 1 1
17 61804901 SHROUD 1 1 1 1 1 1
18 61804100 MOTOR MOUNTING BRACKET 1 1 1 1 1 1
20 61907210 INNERWALL ASY MEDIUM 1 1 1 1 1 1
20 61821500 DOOR/SLIDE ASY 1 1 1 1 1 1
