Friedrich KUHL + XSTAR R-410A - Manual (Page 15)

Kühl Large chassis Parts List (continued)
REF NO. PART NO. DESCRIPTION EL
36
M
35
-A
SL
28
M
30
-A
SL
28
M
30
-B
SL
36
M
30
-A
YL
24
M
35
-A
25 61817800 BLOWER FRONT 1 1 1 1 1
27 61807257 CONTROL PANEL HOUSING 1 1 1 1 1
28 61807010 PARTITION ASY 1 1 1 1 1
29 61809515 BASEPAN 1
29 61809516 BASEPAN 1
29 61809517 BASEPAN 1 1
29 61809518 BASEPAN 1
30 61807400 DRAINPAN 1 1 1 1 1
31 62400321 STANDARD FILTER ASY LRG 1 1 1 1 1
32 62400134 NUT DRIVER FOR DECO FRONT 1 1 1 1 1
33 62400318 FRONT HANDLE / CONTROL MOUNT 1 1 1 1 1
34 61810000 BRACE SHROUD, LARGE 3 3 3 3 3
35 91400400 COMPRESSOR MOUNTING BOLT 3 3 3 3 3
36 01150934 COMPRESSOR GROMMET 3 3 3 3 3
37 62400422 DECORATIVE FRONT ASSY PKGD LRG 1 1 1 1 1
38 PKWSILL FILTER ACCESS PANEL (SILVER) 1 1 1 1 1
39 60294426 WINGBOARD 1 1 1
40 61819818 SIDE ANGLE FOR WINGBOARD 2 2 2
41 61109514 SUPPORT BRACKETS 2 2 2
42 61819717 TOP ANGLE FOR WINGBOARD 1 1 1
43 60610305 WINDOW SEAL GASKET 1 1 1
44 61717302 CHASSIS SEAL GASKET 1 1 1 1 1
45 61808415 SILL PLATE 1 1 1 1 1
46 61825722 OUTER SHELL LRG 1 1 1 1 1
* 61715800 COUNTER WEIGHT 2 2 2 2
* 61818300 INSUL L/S AIR DECK 1 1 1 1 1
* 61816902 INSUL INNERWALL, LRG 1 1 1 1 1
* 61817600 INSULATION LEFT SIDE PANEL 1 1 1 1 1
* 61937000 LEFT SIDE PANEL 1 1 1 1 1
* PKWIKL WINDOW INSTALLATION KIT 1 1
* 61611702 REAR GRILLE MOUNTING BRACKET 1 1 1 1 1
* 61818522 PAINTED REAR GRILLE 1 1 1 1 1
* 60169120 SCRIPT FRIEDRICH FOR REAR GRILLE 1 1 1 1 1
* 91002900 PUSH NUT FOR FRIEDRICH SCRIPT 3 3 3 3 3
* 61818900 HEATER MOUNTING BRACKET 1 1
* 61813501 SHIELD BOTTOM LRG 4R 1 1
* 61821900 SHIELD HEAT LRG 1 1
* 61820702 CAPACITOR STRAP 1 1 1 1 1
* 61814806 CONNECTOR FOR FRESH AIR 1 1 1 1 1
* 61819601 SHELL GUIDE (PLASTIC) 2 2 2 2 2
* 60846016 ASY PLSTC BAG W/WIK 1 1 1
* 60846017 ASY PLSTC BAG W/O WIK 1 1
* 01900236 DC-2 DRAIN KIT (SILVER)
* 01109004 TOUCH UP SPRAY PAINT (SILVER)
14
