Page 13
Kühl Medium chassis Parts List (continued)
REF NO. PART NO.
DESCRIPTION
EM
18
M
34
-A
EM
24
M
34
-A
SM
18
M
30
-A
SM
21
M
30
-A
SM
24
M
30
-A
YM
18
M
34
-A
21
61817100 DECK
1 1 1 1 1 1
22
61820200 AIRFOIL
1 1 1 1 1 1
25
61817400 BLOWER FRONT
1 1 1 1 1 1
27
61807256 PANEL CONTROL HOUSING MED
1 1 1 1 1 1
28
61804310 PARTITION ASY
1 1 1 1 1 1
29
61803461 BASEPAN
1 1 1
29
61803462 BASEPAN
1 1
1
30
61803800 DRAINPAN
1 1 1 1 1 1
31
62400210 STANDARD FILTER ASY (MED)
1 1 1 1 1 1
32
62400134 NUT DRIVER FOR DECO FRONT
1 1 1 1 1 1
33
62400124 FRONT HANDLE / CONTROL MOUNT
1 1 1 1 1 1
34
61802600 BRACE SHROUD
3 3 3 3 3 3
35
91400400 COMPRESSOR MOUNTING BOLT
3 3 3 3 3 3
36
61028900 COMPRESSOR GROMMET
3 3 3 3 3 3
37
62400421
DECORATIVE FRONT (COMPLETE)
1 1 1 1 1 1
38
PKWSILM
FILTER ACCESS PANEL (SILVER)
1 1 1 1 1 1
39
60294421 WINGBOARD
1 1 1
40
61819817 SIDE ANGLE FOR WINGBOARD
2 2 2
41
61109514 SUPPORT BRACKETS
2 2 2
42
61819715 TOP ANGLE FOR WINGBOARD
1 1 1
43
60610305 WINDOW SEAL GASKET
1 1 1
44
61717302 CHASSIS SEAL GASKET
1 1 1 1 1 1
45
61808414 SILL PLATE
1 1 1 1 1 1
46
61825721
OUTER SHELL ASY MEDIUM
1 1 1 1 1 1
*
61715800 COUNTER WEIGHT
2 2 2 2 2 2
*
61816800 INSUL L/S AIR DECK
1 1 1 1 1 1
*
61816901 INSUL INNERWALL MEDIUM
1 1 1 1 1 1
*
61817001 INSULATION LEFT SIDE PANEL
1 1 1 1 1 1
*
61937100 LEFT SIDE PANEL
1 1 1 1 1 1
*
PKWIKM
WINDOW INSTALLATION KIT
1 1
1
*
61611701 REAR GRILLE MOUNTING BRACKET
1 1 1 1 1 1
*
61818521 PAINTED REAR GRILLE
1 1 1 1 1 1
*
60169120 SCRIPT FRIEDRICH FOR REAR GRILLE
1 1 1 1 1 1
*
91002900 PUSH NUT FOR FRIEDRICH SCRIPT
3 3 3 3 3 3
*
61818900 HEATER MOUNTING BRACKET
1 1
1
*
61812900 SHIELD BOTTOM S/M 3R
1
1
*
61812901 SHIELD BOTTOM S/M 4R
1
*
61821801 SHIELD HEAT MED
1 1
1
*
61820700 CAPACITOR STRAP
1 1 1 1 1 1
*
61814805 CONNECTOR FOR FRESH AIR
1 1 1 1 1 1
*
61819601 SHELL GUIDE (PLASTIC)
2 2 2 2 2 2
*
60846016 ASY PLSTC BAG W/WIK
1 1 1
*
60846017 ASY PLSTC BAG W/O WIK
1 1
1
*
01900236
DC-2 DRAIN KIT (SILVER)
*
01109004
TOUCH UP SPRAY PAINT (SILVER)
