Kühl Small chassis Parts List (continued)
10
REF NO. PART NO. DESCRIPTION ES
12
M
33
-A
ES
12
M
33
-B
ES
15
M
33
-A
SS
08
M
10
-A
SS
10
M
10
-A
SS
10
M
10
-B
SS
12
M
10
-A
SS
12
M
30
-A
SS
12
M
30
-B
SS
14
M
10
-A
SS
15
M
30
-A
YS
10
M
10
-A
YS
12
M
33
-A
11 61871441 FAN MOTOR 1 1 1 1 1 1 1
11 61871444 FAN MOTOR 1 1 1 1 1 1
12 60500390 SUPPLY CORD 1 1 1 1 1 1
12 60500394 SUPPLY CORD 1 1 1
12 60500398 SUPPLY CORD 1 1 1 1
13 60179903 BELLOWS CONDENSATE VALVE 1 1 1 1 1
14 60610603 BLOWER WHEEL, EVAPORATOR 1 1 1 1 1
14 60610604 BLOWER WHEEL, EVAPORATOR 1 1 1 1 1 1 1 1
15 61914905 SCROLL SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
16 60542003 FAN BLADE, CONDENSER 1 1 1 1 1 1 1 1 1 1 1 1 1
17 61803601 SHROUD 1 1 1 1 1 1 1 1 1 1 1 1 1
18 61802500 MOTOR MOUNTING BRACKET 1 1 1 1 1 1 1 1 1 1 1 1 1
20 61907310 INNERWALL ASY SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
20 61821500 DOOR/SLIDE ASY 1 1 1 1 1 1 1 1 1 1 1 1 1
21 61817100 DECK 1 1 1 1 1 1 1 1 1 1 1 1 1
22 61820200 AIR FOIL 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61816800 INSUL L/S AIR DECK 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61816900 INSUL INNERWALL SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
25 61817300 BLOWER FRONT 1 1 1 1 1 1 1 1 1 1 1 1 1
27 61807255 PANEL CONTROL HOUSING SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
28 61802810 PARTITION ASY 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61817000 INSULATION LEFT SIDE PANEL 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61937200 LEFT SIDE PANEL 1 1 1 1 1 1 1 1 1 1 1 1 1
29 61803457 BASEPAN 1 1 1
29 61803459 BASEPAN 1 1 1 1
29 61803461 BASEPAN 1 1 1 1
29 61803462 BASEPAN 1 1
30 61803800 DRAIN PAN 1 1 1 1 1 1 1 1 1 1 1 1 1
31 62400127 AIR FILTER ASY (SMALL) 1 1 1 1 1 1 1 1 1 1 1 1 1
32 62400134 NUT DRIVER FOR DECO FRONT 1 1 1 1 1 1 1 1 1 1 1 1 1
33 62400124 FRONT HANDLE / CONTROL MOUNT 1 1 1 1 1 1 1 1 1 1 1 1 1
34 61802600 BRACE SHROUD 3 3 3 3 3 3 3 3 3 3 3 3 3
35 91400400 COMPRESSOR MOUNTING BOLT 3 3 3 3 3 3 3 3 3 3 3 3 3
36 61028900 COMPRESSOR GROMMET 3 3 3 3 3 3 3 3 3 3 3 3 3
37 62400420 DECORATIVE FRONT ASY PKGD SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
38 PKWSILS FILTER ACCESS PANEL (SILVER) 1 1 1 1 1 1 1 1 1 1 1 1 1
39 60294416 WINGBOARD 1 1 1 1 1 1 1 1
40 61819816 SIDE ANGLE FOR WINGBOARD 2 2 2 2 1 2 2 2
41 61109514 SUPPORT BRACKETS 2 2 2 2 1 2 2 2
42 61819715 TOP ANGLE FOR WINGBOARD 1 1 1 1 1 1 1 1
43 60610305 WINDOW SEAL GASKET 1 1 1 1 1 1 1 1
44 61717302 CHASSIS SEAL GASKET 1 1 1 1 1 1 1 1 1 1 1 1
45 61808414 SILL PLATE 1 1 1 1 1 1 1 1 1 1 1 1 1
46 61825720 OUTER SHELL ASY SMALL 1 1 1 1 1 1 1 1 1 1 1 1 1
* PKWIKS WINDOW INSTALLATION KIT 1 1 1 1 1
* 61611700 REAR GRILLE MOUNTING BRACKET 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61818520 PAINTED REAR GRILLE 1 1 1 1 1 1 1 1 1 1 1 1 1
* 60169120 SCRIPT FRIEDRICH FOR REAR GRILLE 1 1 1 1 1 1 1 1 1 1 1 1 1
* 91002900 PUSH NUT FOR FRIEDRICH SCRIPT 3 3 3 3 3 3 3 3 3 3 3 3 3
* 61818900 HEATER MOUNTING BRACKET 1 1 1 1
* 61812900 SHIELD BOTTOM S/M 3R 1 1 1
* 61812901 SHIELD BOTTOM S/M 4R 1
* 61821800 SHIELD HEAT SMALL 1 1 1 1
* 61820700 CAPACITOR STRAP 1 1 1 1 1 1 1 1 1 1 1 1
* 61820702 CAPACITOR STRAP 1
* 61814805 CONNECTOR FOR FRESH AIR 1 1 1 1 1 1 1 1 1 1 1 1 1
* 61819601 SHELL GUIDE (PLASTIC) 2 2 2 2 2 2 2 2 2 2 2 2 2
* 60846016 ASY PLSTC BAG W/WIK 1 1 1 1 1 1 1 1
* 60846017 ASY PLSTC BAG W/O WIK 1 1 1 1 1
* 61715800 COUNTER WEIGHT 3 3 3 3 3 3 3 3 3 3 3
* 01900236 DC-2 DRAIN KIT (SILVER)
* 01109004 TOUCH UP SPRAY PAINT (SILVER)
