5
XStar ® Parts List
REF NO. PART NO. DESCRIPTION EQ
08
M
11
-A
EQ
08
M
11
-B
XQ
05
M
10
-A
XQ
05
M
10
-B
XQ
06
M
10
-A
XQ
08
M
10
-A
XQ
08
M
10
-B
XQ
10
M
10
-A
1 61896026 CONDENSER COIL 1 1 1 1 1 1 1 1
2 61600271 EVAPORATOR COIL 1
2 62050024 EVAPORATOR COIL 1
2 62050026 EVAPORATOR COIL 1 1 1 1 1 1
3 61717103 COMPRESSOR KIT 1
3 61717101 COMPRESSOR KIT 1
3 61717102 COMPRESSOR KIT 1 1
3 61717105 COMPRESSOR KIT 1
3 61717104 COMPRESSOR KIT 1
3 61717154 COMPRESSOR KIT 1 1
* 03760502 CAPILLARY TUBE 1
* 03760545 CAPILLARY TUBE 1 1
* 03760548 CAPILLARY TUBE 1
* 03760550 CAPILLARY TUBE 1 1 1 1
* 61828202 LIQUID DRIER 1 1 1 1 1 1 1 1
4 61921210 ELECTRONIC CONTROL BOARD 1 1 1 1 1 1
* 61826610 REMOTE CONTROL 2010 RAC & WM 1 1 1 1 1 1
* 60441610 SYSTEM SWITCH (ROTARY) 1 1
* 61822401 THERMOSTAT 1 1
* 61080528 CAPACITOR 1
* 61080530 CAPACITOR 1 1 1
* 61080550 CAPACITOR 1 1
* 61080580 CAPACITOR 1 1
5 61764558 OVERLOAD 1 1
5 61764559 OVERLOAD 1
5 61764563 OVERLOAD 1
5 61764596 OVERLOAD 1
5 61764597 OVERLOAD 1 1
5 61764598 OVERLOAD 1
6 61871451 FAN MOTOR 1 1 1 1 1 1 1 1
7 61929611 HEATER 1.15 KW @ 115V 1 1
8 60500380 SUPPLY CORD 1 1 1 1 1 1 1 1
9 61923901 CONTROL MOUNTING BRACKET 1 1 1 1 1 1
10 61928801 PANEL BLWR FRONT EQ 2003 1 1
11 61924300 LEFT SIDE PANEL 1 1 1 1 1 1 1 1
12 61990700 BLOWER FRONT 1 1 1 1 1 1
13 61990701 TOP BLOWER FRONT 1 1 1 1 1 1 1 1
14 60610606 BLOWER WHEEL, EVAPORATOR 1 1 1 1 1 1
14 60610612 BLOWER WHEEL, EVAPORATOR 1 1
15 61990606 SCROLL Q CHASSIS 1 1 1 1 1 1 1 1
16 61634001 CONDENSER FAN BLADE 1 1 1 1 1 1 1 1
17 61627601 SHROUD 1 1 1 1 1 1 1 1
18 61597317 INNERWALL XQ 1 1 1 1 1 1
18 61597318 INNERWALL EQ 1 1
