SK-96370-144PMC-GDC User Guide
Chapter 1 Overview
© Fujitsu Microelectronics Europe GmbH
- 9 -
FMEMCU-UG-960014-10
1.3.8 I2C Bus
Additional 10 kOhm pull-up resistors can be connected to the I²C bus lines by setting the
according jumpers. JP9 is for SDA0 and JP10 for SCL0.
1.3.9 Emulator System
If the board is used as an emulator target board, the microcontroller must be removed from
the socket and the corresponding probe cable has to be mounted:
Table 1-1: Emulation System
Series
V-Chip
Probe cable
Socket
MB96370 MB96V300B
MB2198-507-E
NQPACK144SD-ND
HQPACK144SD
