FUJITSU MB96300 User Manual
Page 12
SK-96370-144PMC-GDC User Guide
Chapter 2 Installation
FMEMCU-UG-960014-10
- 12 -
© Fujitsu Microelectronics Europe GmbH
Jumper
Description / Function
Type
Default
Setting
Coordinates
JP42
UART2 : LIN VBat
Jumper 2 pin
Open
K 3
JP43
UART2 : LIN-Enable
Jumper 2 pin
Open
L 3
JP44
LIN2 Transceiver type
Solder JP 3 pin
1-2 L
5
JP45
UART2 : LIN Master
Jumper 2 pin
Open
M 3
JP46
Direct Reset / Delayed
Solder JP 3 pin
1-2 J
7
JP47
Voltage Monitor
Solder JP 3 pin
2-3 J
8
JP48
MCU Reset
Jumper 2 pin
Closed
J 8
JP49
FLASH : Word / Byte access
Jumper 3 pin
1-2
D 13
JP50
SRAM : Word / Byte access
Jumper 3 pin
1-2
F 13
JP52
FLASH : 16-bit / 8-bit interface
Jumper 3 pin
1-2
D 13
JP53
SRAM : 16-bit / 8-bit interface
Jumper 3 pin
1-2
F 13
JP54
Set A24 to GND for GDC interface
Solder JP 2 pin
Closed C
15
JP55
Set A25 to GND for GDC interface
Solder JP 2 pin
Closed C
16
JP56
FLASH / LIME
Jumper 4 pin
2-4
E 14
JP57
Select CS3/CS2 for GDC interface
Jumper 2 pin
Open
E 14
JP58
Supply 1V8 to GDC interface
Solder JP 2 pin
Closed C
4
JP59
SRAM
Jumper 3 pin
2-3
E 13
JP60
External Vin
Solder JP 2 pin
Open C
8
JP70
Manual GDC reset (GLRST)
Solder JP 2 pin
Closed C
7
JP71
Manual GDC reset (FLRST)
Solder JP 2 pin
Closed C
7
JP85
ALARM0
Jumper 2 pin
Closed
L 15
Table 2-1: Jumper Settings
