SK-96370-144PMC-GDC User Guide
Chapter 1 Overview
© Fujitsu Microelectronics Europe GmbH - 7 - FMEMCU-UG-960014-10
1.2 Features
< Supports Fujitsu’s 16FX MB96370 Series with 144 pin PMC / M08 package
or the MB2198 Emulator System with the Probe Cable MB2198-507-E.
< 9-15V unregulated external DC power supply
< On-board 3.3V switching mode voltage regulator
< Power-LEDs for all supply voltages
< Onboard voltage supervisor monitor
< In-Circuit serial Flash programming (UART0 or UART2)
< All resources available for evaluation
< All MCU pins routed to connectors
< 4 MHz main crystal
< 32 kHz crystal for sub clock operation
< Two RS232- or LIN interfaces
< Two CAN interfaces
< 3 V capable CAN, LIN, and RS232 transceivers
< 8 User LEDs
< Optional: alphanumeric standard LC-Display connectable instead of LEDs
< Reset button, Reset LED
< 5 User buttons
< 8 MByte FLASH
< 2 MByte SRAM
< Connector for Fujitsu Graphic-Controller boards (e.g.: CREMSON-STARTERKITLIME)
< External bus interface routed to 96 pin and 48 pin DIN 41612 (VG) connectors
< Power Supply: 5V, 3.3V, 2.5V and 1.8V
This board must only be used for test applications
in an evaluation laboratory environment.
